Power Bangladesh

Dalian Tucheng International Co.,Limited(TCI) was established in 1996 which focuses on electric products, marketing, services and logistics. It is an important manufacturer and exporter with several decades of experience in designing, researching, manufacturing, testing and logistics.

TCi has great experiences in Bangladesh electric market.

2016-2017，BPDP Power Distribution System Development Project (Rangpur Zone),Bangladesh.

Jun,2015.Chittagong Zone  Electricity Distribution System Development Project, Bangladesh Power Development Board Chittagong.

Oct,2014.TCI supplied Post insulators and Substation hardware fittings for “52.2MW power plant project at Daiara, P.O. Ahammed Nagar, Jangalia, Comilla, Bangladesh” successfully.

The persons who will attend Power Bangladesh exhibition.

Stanley Yun  Sales & Technical Director • Marketing strategy • Sales management • Design & Engineering	Brenda Xiong Project manager (mainly Bangladesh Projects) • insulator sales • Customer service • Project management

Some hot sale insulators you may be interested in.

Type Diameter (mm) Height (mm) Leakage (mm) SML (kN) U40B 190 140 200 40 U70B 255 146 295 70 U80B 255 146 295 80 U100B 255 146 295 100 U120B 255 146 320 120 U160B 255 146 400 160 U210B 280 170 380 210 U240B 280 170 405 240 U300B 320 195 370 300 U400B 360 205 525 400 U530B 380 240 600 530

Fog type

Type Diameter (mm) Height (mm) Leakage (mm) SML (kN) U70BP 255 146 432 70 U80BP 255 146 432 80 U100BP 255 146 432 100 U120BP 280 146 440 120 U160BP 320 170 525 160 U210BP 330 170 550 210 U240BP 320 170 550 240 U300BP 380 195 690 300

Porcelain disc insulator with RTV coating type

Pollution is becoming more and more serious in many areas. So disc insulators with RTV coating are increasingly popular. It has unique characteristics:

• Resistance to tracking and erosion

• Resistance to weathering & UV

• Resistance to chemical & physical degradation by water

• Volume resistivity

• Resistance to corona & ozone

• Application onto glass or porcelain surfaces, especially when done in the field

Note: ANSI 52-1, 52-2, 52-3, 52-4, 52-5,52-8 and 52-10 are available too.

Glaze color: grey, brown

Production process

Material → Crush  → Mixture →Crinding →Screening →De-ironing →Slip Pool →Filtering →Kncading →Ageing →Vacuum Pugging → Electro-drying →Shaping →Glazing and Sanding →Firing →Assembling →Curing →Sample test  → Rountine test →Packing  →Storage → Departure

Manufactured and test in accordance    with IEC 60383 ANSI C29.1 C29.2

Application   ·Overhead transmission or distribution line   ·Tension tower to assembly tension string to tensile     conductor   ·Suspension tower to assenbly suspension string to     suspend conductor   ·Substation
